Vertical Lightweight Double-Head Material Rack

Vertical Lightweight Double-Head Material Rack

Basic Attributes

  • Model CMMT
  • Coil Width 500 mm

Models List

  • CMMT-100D
  • CMMT-150D
  • CMMT-200D
  • CMMT-300D
  • CMMT-400D
  • CMMT-500D
Contact now
Description

Features of the Vertical Lightweight Double-Head Material Rack:

1.Space-Saving:

The vertical design allows materials to be stored in a vertical position, occupying less floor space, making it ideal for environments with limited space.

2.Double-Head Design:

Equipped with two support points, it can store two rolls of material simultaneously, improving storage and operational efficiency while reducing the need for additional equipment, saving both space and cost.

3.Lightweight and Easy to Move:

The lightweight structure makes the rack easier to transport and reposition, ideal for locations where frequent changes in position or material storage are required.

4.Increased Work Efficiency:

The double-head design enables operators to handle two rolls of material at the same time, saving time and boosting production efficiency.

5.Easy Material Access:

The vertical storage method makes it easier to retrieve and place materials, reducing time spent searching and handling materials, especially when accessing from higher positions.

6.Sturdy Structure with Strong Support:

Despite its lightweight design, the rack still offers adequate support, making it suitable for materials of various weights and sizes.

7.Wide Range of Applications:

Suitable for a variety of materials, such as metal coils, plastic films, paper rolls, etc., offering strong adaptability and flexibility.

8.Improved Safety:

Materials are stored securely, reducing the risk of material dropping or damage, helping to enhance workplace safety.


Product Specification
Item CMMT-100D CMMT-150D CMMT-200D CMMT-300D
Material Width mm 100 150 200 300
Rack Load Capacity kg 150*2 300*2 500*2 800*2
Inner Diameter of Coil mm φ450-530 φ450-530 φ450-530 φ450-530
Outer Diameter of Coil mm φ1200 φ1200 φ1200 φ1200
Item CMMT-400D CMMT-500D
Material Width mm 400 500
Rack Load Capacity kg 1500*2 2000*2
Inner Diameter of Coil mm φ450-530 φ450-530
Outer Diameter of Coil mm φ1200 φ1200
