V-Gear Type Automatic Tapping Machine
Basic Attributes
- 型号 CMCX-6516V
- 型号 CMCX-6516V
- 型号 CMCX-6516V
- 工作台尺寸 L720*W650*H670 mm
- 工作台尺寸 L720*W650*H670 mm
Models List
-
CMCX-6516V
Product Specification
| Item | CMCX-6516V |
|---|---|
| Spindle Stroke mm | 65 |
| Tapping Diameter Range | M2-M16 |
| Vertical Movement Distance of Main Unit mm | 0-300 |
| Distance from Spindle to Worktable mm | 100-350 |
| Worktable Size mm | L720 x W650 x H670 |
| Base Size mm | L590 x W420 |
| Motor Power kw | 1.5 |
| Spindle Speed | 50Hz: 590, 400, 250; 60Hz: 720, 480, 300 |
| Thread Pitch (Imperial) | 10, 11, 12, 14, 16, 18, 19, 20, 24, 28, 32 |
| Thread Pitch (Metric) | 4, 0.45, 0.5, 0.7, 0.75, 0.8, 1.0, 1.25, 1.5, 1.75, 1.8, 2.0,2.5 |
| Maximum Tapping Capacity (Multi-Spindle) | M1 x 13, M5 x 10, M6 x 7, M8 x 4, M10 x 3, M12 x 2, M16 x 1 |
