SAF Roll Feeder

Features:

1. High-precision feeding:
2. Aiming at the arrival of hi-tech industry, it is using close-loop feedback control computer system and high resolution encoder to make feeding precision within ±0.03mm ( varied model has varied accuracy ).
3. Programmable feeding function:
4. Provide max. 40 groups of different feeding length, each group provide 999 times punching to satisfy the special manufacture process. (option)
5. Humane Manual mode:
6. Can input 3 different manual speeds to provide user operate more easily and feed materials more accuracy.
7. High efficiency release device:
8. Quickly set up release angle base on press’s Cam signal and simply material thickness adjustment.
9. Control panel function:
10. Designed feed length, count, speed & angle function key for quickly setting. Feed length from 0.01mm to 9999.99mm.
11. Feeding unit:
12. The rollers adopt middle hollow style to be light and low inertia for electroplate. Roller surface hardness is HRC60° and hard chromium plated to extend lifetime.
13. Suit to different thickness and width for long feed length product.
